Description
The new 4TS-8T Teleskid has the high torque, high power and performance to reach further and lift higher than any other skid steer on the market. With a powerful 4.4L engine delivering 109hp, our new vertical lift machine makes lifting and loading easy. And with a wide choice of attachments to use, it takes versatile performance to a whole new level.
Specifications
Manufacturer
JCB
Model
4TS-8T
Year
2026
Category
Skid Steers
Subcategory
Teleskid
Engine Model
EcoMAX TCAE-81
Cylinders
4
Aspiration
Turbo
Cooling
Water
Displacement
4.4 L [268 cu in]
Hydraulic Power
26.7 kW [35.8 hp]
Hydraulic Power - Option
59.7 kW [77.7 hp]
Pump Flow
90 L/min [24 gal/min]
Pump Flow - Option
160 L/min [42.3 gal/min]
System Pressure
280 bar [4061 psi]
System Pressure - Option
280 bar [4061 psi]
Hydraulic System
55 L [14.5 gal]
Length - With Bucket
4000 mm [158 in]
Width - No Bucket
1900 mm [75 in]
Width - With Bucket
1900 mm [75 in]
Height - Top Of Cab
2000 mm [82 in]
Ground Clearance
180 mm [7 in]
Track Length On Ground
2100 mm [83 in]
Height To Hinge Pin
3600 mm [142 in]
Max Dump Height
2900 mm [114 in]
Max Dump Height Reach
700 mm [28 in]
Turning Radius - Rear Corner
1900 mm [75 in]
Turning Radius - Bucket Corner
2400 mm [95 in]
Rear Departure Angle
29°
Dump Angle
28°
Ground Level Rollback
34°
Platform
LiveLink
Emissions
Diesel T4
Features
Retracted Boom
Undercarriage Type
Hi Mount Drive Motor
Lift Geometry
Vertical
Access
Side Entry - Left
Structure
ROPS / FOPS
ROPS Rating Standard
ISO 3471
FOPS Rating Standard
ISO 3449
Cab Type
Swing Up
Gross Rating Standard
SAE J1995
Gross Output
81 kW [109 hp]
Torque Rated Speed
1200 rpm
Torque
516 Nm [380 lbf·ft]
Transmission Type
Hydrostatic
Motors
2
Drive Method
Sprocket
Steering Type
Track
Track Rollers
5
Track Type
Rubber
Fuel Tank
103.3 L [27.3 gal]
Engine Oil
15 L [4 gal]
Cooling System
22 L [5.8 gal]
Tipping Load
5183 kg [11426 lb]
Operating Capacity
1814 kg [3999 lb]
Speed - Maximum
12.5 km/h [7.8 mph]
Breakout - Lift
30 kN [6638 lbf]
Breakout - Bucket
35 kN [7919 lbf]
Controls - Loader
Joystick
Controls - Steering
Joystick
Self Levelling
Hydraulic [Opt]
Operating Weight
5897 kg [13000 lb]
