Description
Introducing a unique machine with endless possibilities. The JCB Teleskid is the first skid steer or compact tracked loader with a telescopic boom, making it the most versatile machine you’ve ever seen. It can reach higher, further and deeper than any other skid steer on the market, and it can access areas you wouldn’t have thought possible.
Specifications
Manufacturer
JCB
Model
3TS-8T
Year
2026
Category
Skid Steers
Subcategory
Teleskid
Emissions
Diesel T4 SIIIB
Engine Oil
14 L [3.7 gal (US)]
Engine Manufacturer
JCB
Engine Model
EcoMAX TCAE-55
Cylinders
4
Aspiration
Turbo
Cooling
Water
Displacement
4.4 L [268 in³]
Rated Speed
2400 rpm
Gross Rating Standard
SAE J1995
Gross Output
55 kW [74 hp]
Torque Rated Speed
1200 rpm
Torque
400 Nm [295 lb/ft]
Hydraulic Power - Option
47.44 kW [64 hp]
Pump Flow
90 L/min [24 gal (US)/min]
Pump Flow - Option
125 L/min [33 gal (US)/min]
System Pressure
230 bar [3335 psi]
System Pressure - Option
230 bar [3335 psi]
Rear Departure Angle
29°
Dump Angle
42°
Ground Level Rollback
30°
Full Height Rollback
94°
Track Shoe Width
450 mm [17.7 in]
Length - No Bucket
3020 mm [119 in]
Length - With Bucket
3800 mm [149 in]
Width - No Bucket
2000 mm [77 in]
Width - With Bucket
1850 mm [73 in]
Height - Top Of Cab
2100 mm [83 in]
Ground Clearance
238 mm [9.4 in]
Track Length On Ground
2100 mm [83 in]
Track Gauge
1550 mm [59.3 in]
Height To Hinge Pin
3200 mm [126 in]
Max Dump Height
2400 mm [94 in]
Max Dump Height Reach
700 mm [27 in]
Lift Height
2900 mm [114 in]
Turning Radius - Rear Corner
1760 mm [69 in]
Turning Radius - Bucket Corner
2300 mm [90 in]
Undercarriage Type
Hi Mount Drive Motor
Lift Geometry
Vertical & Radial
Access
Side Entry - Left
Structure
ROPS / FOPS
ROPS Rating Standard
ISO 3471
FOPS Rating Standard
ISO 3449
Cab Type
Swing Up - Meshed
Transmission Type
Hydrostatic
Transmission Motors
2
Drive Method
Sprocket
Steering Type
Track
Track Rollers
5
Track Type
Rubber
Fuel Tank
103 L [27.2 gal (US)]
Hydraulic System Capacity
55 L [14.5 gal (US)]
Cooling System
22 L [5.8 gal (US)]
Heaped Capacity
0.43 m³ [15 ft³]
Tipping Load
4789 kg [10558 lb]
Operating Capacity
1676 kg [3695 lb]
Speed - Maximum
9.2 kph [5.7 mph]
Breakout - Lift
24.7 kN [5557 lbf]
Breakout - Bucket
28.9 kN [6517 lbf]
Controls - Loader
Joystick
Controls - Steering
Joystick
Operating Weight
5722 kg [12615 lb]
