Description
With high horsepower and torque, the JCB 400T Compact Track Loader is more than a match for any job you can think of. With a powerful 4.4L engine delivering 109hp, our new vertical lift machine makes lifting and loading easy. And with a wide choice of attachments to use, it takes versatile performance to a whole new level.
Specifications
Manufacturer
JCB
Model
400T
Year
2026
Category
Skid Steers
Subcategory
Compact Track Loaders
Engine Model
EcoMAX TCAE-81
Engine Manufacturer
JCB
Cylinders
4
Aspiration
Turbo
Cooling
Water
Displacement
4.4 L [268 cu in]
Gross Rating Standard
SAE J1995
Gross Output
81 kW [109 hp]
Hydraulic Power
26.7 kW [35.8 hp]
Hydraulic Power - Option
59.7 kW [77.7 hp]
Pump Flow
90 L/min [24 gal/min]
Pump Flow - Option
160 L/min [42.3 gal/min]
System Pressure
280 bar [4061 psi]
System Pressure - Option
280 bar [4061 psi]
Hydraulic System
55 L [14.5 gal]
Length - With Bucket
3900 mm [153 in]
Width - No Bucket
1900 mm [75 in]
Width - With Bucket
1900 mm [75 in]
Height - Top Of Cab
2000 mm [82 in]
Ground Clearance
180 mm [7 in]
Track Length On Ground
2100 mm [83 in]
Track Gauge
1530 mm [60.3 in]
Height To Hinge Pin
3100 mm [123 in]
Max Dump Height
2311 mm [91 in]
Max Dump Height Reach
880 mm [34 in]
Turning Radius - Rear Corner
1900 mm [75 in]
Turning Radius - Bucket Corner
2300 mm [91 in]
Rear Departure Angle
29°
Dump Angle
39°
Ground Level Rollback
30°
Platform
LiveLink
Emissions
Diesel T4 SIIB
Undercarriage Type
Hi Mount Drive Motor
Lift Geometry
Vertical
Access
Side Entry - Left
Structure
ROPS / FOPS
ROPS Rating Standard
ISO 3471
FOPS Rating Standard
ISO 3449
Cab Type
Swing Up
Transmission Type
Hydrostatic
Motors
2
Drive Method
Sprocket
Steering Type
Track
Track Rollers
5
Track Type
Rubber
Fuel Tank
103.3 L [27.3 gal]
Engine Oil
15 L [4 gal]
Cooling System
22 L [5.8 gal]
Tipping Load
5178 kg [11415 lb]
Operating Capacity
1811 kg [3994 lb]
Speed - Maximum
12.5 km/h [7.8 mph]
Breakout - Lift
30 kN [6816 lbf]
Breakout - Bucket
36 kN [8150 lbf]
Controls - Loader
Joystick
Controls - Steering
Joystick
Self Levelling
Hydraulic [Opt]
Operating Weight
5689 kg [12544 lb]
