Description
Tracked excavators have been a part of the JCB manufacturing family for over 50 years. Using all of this experience and insight, our latest mini diggers like the new 50Z-1 have been developed to exceed even your most exacting demands. Put simply, this is one of the strongest and highest performing mini excavators we’ve ever built. It’s highly productive, compact, agile, innovative and economical to own. Not only that but it’s very safe to operate and easy to service too.
Specifications
Manufacturer
JCB
Model
50Z-1
Year
2026
Category
Excavators
Subcategory
Compact Excavators
Engine Model
KDI 1903
Cooling
Water
Displacement
1.9 L [116 cu in]
Rated Speed
2200 rpm
Net Output
33.4 kW [44.8 hp]
Gross Rating Standard
ISO 14396
Gross Output
36 kW [48.3 hp]
Torque
225 Nm [165.9 lbf·ft]
Torque Rated Speed
1500 rpm
Main Pumps
1
Main Pump Flow
126 L/min [33.2 gal/min]
Boom Pressure
240 bar [3480 psi]
Arm Pressure
240 bar [3480 psi]
Attachment Pressure
240 bar [3480 psi]
Boom Size
2.7 m [8 ft 10 in]
Min Arm Length
1570 mm [5 ft 1 in]
Standard Arm Length
1570 mm [5 ft 1 in]
Length
5353 mm [17 ft 6 in]
Height
2561 mm [8 ft 4 in]
Width - Overall
1950 mm [6 ft 4 in]
Track Length On Ground
2000 mm [6 ft 6 in]
Undercarriage Length
2490 mm [8 ft 2 in]
Tail Swing Radius
975 mm [3 ft 2 in]
Ground Clearance
300 mm [12 in]
Track Gauge
1550 mm [5 ft 1 in]
Width Over Tracks
1950 mm [6 ft 4 in]
Digging Reach
6119 mm [20 ft]
Ground Level Reach
5995 mm [19 ft 8 in]
Dig Height
5664 mm [18 ft 6 in]
Dump Height
4274 mm [14 ft]
Vertical Wall
2052 mm [6 ft 8 in]
Dig Depth
3843 mm [12 ft 7 in]
Front Slew Radius
2641 mm [8 ft 7 in]
Front Slew Radius - Swing Boom
2160 mm [7 ft 1 in]
Boom Swing - Left
70°
Boom Swing - Right
55°
Emissions
Diesel T4
Operating Weight
4800 kg [10583 lb]
Number Of Boom Options
1
Number Of Mono Booms
1
Number Of Arm Options
1
Carrier Rollers Per Side
1
Track Rollers Per Side
4
Shoe Width
400 mm [15.7 in]
Shoe Type
Rubber
Fuel Tank
76 L [20 gal]
Engine Oil
8 L [2 gal]
Cooling System
9.2 L [2.4 gal]
Hydraulic Tank
55 L [14.5 gal]
Hydraulic System
100 L [26.4 gal]
Ground Bearing Pressure
28.9 kPa [4.2 psi]
Travel Speed - Low
3 km/h [1.8 mph]
Travel Speed - High
4.6 km/h [2.8 mph]
Tractive Force
35.7 kN [8025 lbf]
Arm Tearout
22 kN [4945 lbf]
Bucket Breakout
38 kN [8542 lbf]
Transport Weight Mono Boom
4800 kg [10583 lb]
